"Serving the abrasive blasting and painting industry since 1992"
CAPASCO, INC. has been serving the blasting and paint industry with quality equipment and service for over 30 years. With knowledge gained through experience, we are able to provide excellent service and support to our valued customers. Whether you are looking for parts and accessories, or a new blast and paint facility, we can help you get the right equipment to get the job done.
fEATURED PRODUCT
DRY LAND AIR DRYER
Pirate Brand® Dry Land™ Single Tower, Deliquescent, Air Dryers are a skid mounted system which includes an after cooler, a coalescing filter, and a single tower dryer filled with desiccant tablets. Warm compressed air enters the aftercooler where it is cooled to a 10°F to 15°F (5.6°C to 8.3°C) approach to ambient air temperature, water is condensed out during this cooling process. The saturated air and liquid water pass through a coalescing filter where any oil contaminants from the compressor are removed and then proceed to the inlet of the dryer tank. The water and any solid particles present are separated by gravity and fall to the bottom of the dryer tank. The air moves up through the desiccant tablets which absorb the moisture from the air dropping the relative humidity before it flows through the dryer outlet. The tablets dissolve gradually as they absorb the moisture. The dissolved desiccant and water falls to the bottom of the vessel. The dryer must be drained periodically to remove the accumulated solution. A manual ball valve is installed for this purpose.
DRY LAND AFTER COOLER
Pirate Brand® Dry Land™ After Coolers are a skid mounted system which includes an after cooler, a moisture filter, and a coalescing filter. Warm air enters the aftercooler where it is cooled to a 10°F to 15°F (5.6°C to 8.3°C) approach to ambient air temperature, water is condensed out during this cooling process. The saturated air and liquid water pass through a moisture separator where airborne water droplets are separated out. Next the air passes through a coalescing filter where any oil contaminants from the compressor are removed before it flows through the after cooler outlet.
Click Here to request a quote or further product Information
